Dual-Outlet Digital Water Timer (Battery Powered)
Brand Chemical Supplies provides the Dual-Outlet Digital Water Timer, a professional-grade solution for automating irrigation and fluid management. This battery-powered unit allows you to control two separate watering zones from a single faucet, providing high-precision scheduling for gardens, greenhouse misting systems, and small-scale industrial rinse cycles.
Technical Specifications
| Feature | Specification |
| Outlets | 2 \times$ Independently Programmable Ports |
| Inlet Thread | 3/4″ (25 mm) or 1″ (32 mm) BSP |
| Working Pressure | 0.5 \sim 8.0 Bar |
| Flow Rate | Up to 35 Liters per minute per outlet |
| Power Source | 2 \times AA Alkaline Batteries (Not included) |
| Watering Duration | 1 minute to 240 minutes |
| Watering Frequency | 4 hours to 15 days |
Key Features & Benefits
-
Independent Dual-Zone Control: Each outlet can be programmed with its own start time, duration, and frequency. This is ideal for systems requiring different flow rates, such as high-flow sprinklers on Zone 1 and low-flow drip irrigation on Zone 2.
-
Weather-Resistant Construction: The unit features a waterproof battery compartment and a rugged, UV-stabilized housing designed to withstand the harsh South African sun and seasonal rains.
-
Manual Override Mode: Need to wash the car or fill a bucket? The “Manual” button allows you to access water instantly without disrupting your pre-set automated schedules.
-
Rain Delay Function: To conserve water, the timer includes a manual delay feature (24, 48, or 72 hours). This pauses your irrigation schedule during rainy weather and automatically resumes when the delay expires.
-
Large Easy-to-Read LCD: The high-contrast digital display provides a clear view of the current time, next scheduled watering, and remaining battery life.
-
Low Battery Safety: The timer includes an automatic shut-off safety feature; if battery power drops below a critical level, the valves will fail-safe to the “Closed” position to prevent water wastage.
Primary Applications
-
Greenhouse Management: Automating misting systems for humidity control and drip lines for nutrient delivery.
-
Commercial Landscapes: Managing irrigation for office parks and residential complexes where two distinct plant types (e.g., lawn vs. succulents) are used.
-
Industrial Rinsing: Setting timed rinse cycles for equipment or containers in facilities without complex PLC-controlled plumbing.
-
Dust Suppression: Intermittent spraying of driveways or construction footpaths.
Installation & Maintenance
-
Direct Tap Mounting: Screw the timer directly onto your outdoor tap. Hand-tighten only; using a wrench can damage the plastic threads.
-
Filter Maintenance: The inlet features a stainless steel mesh filter. We recommend checking and cleaning this every 3 months to prevent grit from affecting the internal solenoid valves.
-
Winter Care: In regions prone to frost, remove the timer from the tap during winter months to prevent internal water from freezing and cracking the valve body.
Contact our irrigation specialists at Brand Chemical Supplies today to secure your Dual-Outlet Water Timers and bring precision automation to your fluid distribution systems.
